Half Cut Solar Panel Monocrystalline PERC Cell 12BB 9BB 5BB 330W 320W 310W 300W 24V 36V Mono Solar P

Detail

Cell size

166mmx166mm

Type

PERC, Half Cell, HJT

Panel Efficiency

21.9%

Warranty

25years

Place of Origin

Jiangsu, China

Panel Dimensions

2094 x 1038 x 35mm

Brand Name

Sunpal

Model Number

H4-144Cell-475W

Type

Half Cell Solar Panel

Front Side Glass

High transparency solar glass 3.2mm

Solar Cells

Monocrystalline

Cell Orientation

144 Cells (6x24)

Weight

23.3kg

Glass

3.2 mm (0.13 inches), High Transmission, AR Coated Tempered Glass

Backsheet

White

Frame

Silver / Black Anodized Aluminium Alloy

Junction Box

IP 68 rated

Cables

4.0mm2

Packaging Details

carton with pallet

1000 Piece/Pieces per Day

Quantity (watts)	1 - 100000	> 100000
Lead time (days)	7	To be negotiated

Maximum Power (Pmax/W)	445	450	455	460	465	470	475
Maximum Power Voltage (Vmp/V)	41.75	42.10	42.41	42.76	43.10	43.44	43.78
Maximum Power Current (Imp/A)	10.66	10.69	10.73	10.76	10.79	10.82	10.85
Open Circuit Voltage (Voc/V)	49.55	49.84	50.10	50.39	50.68	50.96	51.25
Short Circuit Current (Isc/A)	11.31	11.34	11.37	11.40	11.43	11.47	11.50
Module Efficiency (%)	20.5	20.7	20.9	21.2	21.4	21.6	21.9
Power Output Tolerance (W)	0~+5
Temperature Coefficient of Isc	+0.05%/°C
Temperature Coefficient of Voc	-0.28%/°C
Temperature Coefficient of Pmax	-0.36%/°C
