550W Solar Panel Solar Panels 540W 450W 550W 555W In Europe Warehouse Rotterdam

Detail

Key attributes

Industry-specific attributes

Cell size

210mmx210mm

Type

PERC, Half Cell, Bifacial, Double-glass, All Black, HJT, N-TYPE

Panel Efficiency

22%

Warranty

25 /30Years

Other attributes

Place of Origin

Anhui, China

Panel Dimensions

2384 x 1303 x 30mm

Brand Name

SUNPAL Solar

Model Number

HiKu/BiHiku

Weight

33.6kg

Front Side Glass

High transparency solar glass 2.0mm

Back Side Glass

High transparency solar glass 2.0mm

Frame

Silver / Black, anodized aluminium alloy

Junction Box

IP68 Rated, 3 Diodes

Cable

4.0mm2, Portrait: 300mm / Landscape: 1200mm

Wind/Snow Load

2400Pa/5400Pa

Connector

MC Compatible

Application

Residencial,Commercial & Industry

Bifaciality

70±5%

Packaging and delivery

Packaging Details

Carton with Pallets

Port

Shanghai/Ningbo

Supply Ability

5000000000 Watt/Watts per Year

Lead time

Quantity (watts)	1 - 2000000	> 2000000
Lead time (days)	15	To be negotiated

BiHiKu & HiKu Series

Testing Condition	STC
CS6W	530MS	535MS	540MS	545MS	550MS	555MS
Maximum Power（Pmax/W）	530W	535W	540W	545W	550W	555W
Voltage at Maximum Power(Vmp/V)	40.9V	41.1V	41.3V	41.5V	41.7V	41.9V
Current at Maximum Power(Imp/A)	12.96A	13.02A	13.08A	13.14A	13.20A	13.25A
Open Circuit Voltage（Voc/V)	48.8V	49.0V	49.2V	49.4V	49.6V	49.8V
Short Circuit Current(lsc/aA)	13.80A	13.85A	13.90A	13.95A	14.00A	14.05A
Module Efficiency(%)	20.70%	20.90%	21.10%	21.30%	21.50%	21.60%
Testing Condition	NMOT
CS6W	530MS	535MS	540MS	545MS	550MS	555MS
Maximum Power（Pmax/W）	397W	401W	405W	409W	412W	416W
Voltage at Maximum Power(Vmp/V)	38.3V	38.5V	38.7V	38.9V	39.1V	39.3V
Current at Maximum Power(Imp/A)	10.38A	10.42A	10.47A	10.52A	10.55A	10.59A
Open Circuit Voltage（Voc/V)	46.1V	46.3V	46.5V	46.7V	46.9V	47.1V
Short Circuit Current(lsc/aA)	11.13A	11.17A	11.21A	11.25A	11.29A	11.33A
